Product Description

ASTM A519 1010 1020 1026 SRA +N Seamless Steel Tube , Carbon Steel Seamless Tube

ASTM A519 Grade 1020 Carbon Steel Seamless Tubings are Low Carbon Steel Tubings with 0.18-0.23 % carbon content with combination of 0.30-0.60 % manganese. These Tubings are also known as mild steel pipes and tubes. ASTM A519 Grade 1020 Tubings are low-cost Tubings easy to form and shape. These pipes are manufactured as per ASTM Specification and commercially referred as cs pipes or ms pipes. Low Carbon Steel Pipes are not as hard as hig carbon steel pipes,Though carburizing can increase its surface hardness.

Seamless Steel Pipe
Grade:SAE 1020
OD:10.3-610mm
WT:1.24-30mm
Length: 1-12m , can be fixed
Technique:hot rolled,cold rolled,cold drawn

We always keep stocks for SAE 1020 and SAE 1045 seamless pipe stocks with all available sizes, if you have need for them, please contact us freely.

1.Chemical compisition of SAE 1020 & 1045

Grade	C	Si	Mn	P	S	Cr
1020	0.17-0.23	0.17-0.37	0.35-0.65	Max 0.030	Max 0.030	Max 0.25
1045	0.42-0.50	0.17-0.37	0.50-0.80	Max 0.030	Max 0.030	Max 0.25

2.Mechanical property of SAE 1020 & 1045 Seamless Steel Pipes

Grade	Tensile Strength(Mpa)	Yield Strength(Mpa)	Elongation %	Reduction area %
1020	min 410	min 245	min 25	min 55
1045	min600	min355	min 16	min 40

3.Dimentions of SAE 1020 & 1045 Seamless Steel Pipes
OD:10.3-610mm
WT:1.24-30mm
Length: 1-12m , can be fixed

4.Delivery condition and surface:
Hot Rolled-Black
Cold Rolled- Bright
Cold Drawn- Bright
Surface painting to black , blue , red or any color as per request
Galvanized

5.Main grade we can supply:
Carbon steel: SAE1010,SAE1020,SAE1026
Alloy steel: SAE4130,SAE4140

6.Delivery time: within 15 days after deposit.
7.Additional service:
Surface painting
Both end plastic caps
Cutting to small fixed length
8.Payment term: FOB, CFR, CIF ,EXW, FCA and so on.
9.MOQ: 1 ton per size
10.Sample: Freely supplied

ASTM A519 1010 1020 1026 Sra +N Seamless Steel Tube, Carbon Steel Seamless Tube
